Model No.︰12mm-8inch
Brand Name︰-
Country of Origin︰China
Unit Price︰US $ 675 / ton
Minimum Order︰10 ton
erw carbon steel pipe,2 inch galvanized steel pipe,galvanised pipe suppliers,one inch galvanized pipe,1.25 inch galvanized pipe,8 ft galvanized pipe
| Schedule 40 | outside diameter
(in) |
inside diameter
(in) |
wall thickness
(in) |
weight
(lb/ft) |
Schedule 80 | outside diameter
(in) |
inside diameter
(in) |
wall thickness
(in) |
weight
(lb/ft) |
| 1/8 | 0.405" | 0.269" | 0.068" | 0.24 | 1/8 | 0.405" | 0.269" | 0.068" | 0.25 |
| 1/4 | 0.540" | 0.364" | 0.088" | 0.42 | 1/4 | 0.540" | 0.364" | 0.088" | 0.40 |
| 3/8 | 0.675" | 0.493" | 0.091" | 0.57 | 3/8 | 0.675" | 0.493" | 0.091" | 0.58 |
| 1/2 | 0.840" | 0.622" | 0.109" | 0.85 | 1/2 | 0.840" | 0.622" | 0.109" | 0.87 |
| 3/4 | 1.050" | 0.824" | 0.113" | 1.13 | 3/4 | 1.050" | 0.824" | 0.113" | 1.20 |
| 1 | 1.315" | 1.049" | 0.133" | 1.68 | 1 | 1.315" | 1.049" | 0.133" | 1.68 |
| 1-1/4 | 1.660" | 1.380" | 0.140" | 2.27 | 1-1/4 | 1.660" | 1.380" | 0.140" | 2.27 |
| 1-1/2 | 1.900" | 1.610" | 0.145" | 2.72 | 1-1/2 | 1.900" | 1.610" | 0.145" | 2.72 |
| 2 | 2.375" | 2.067" | 0.154" | 3.65 | 2 | 2.375" | 2.067" | 0.154" | 3.65 |
| 2-1/2 | 2.875" | 2.469" | 0.203" | 5.79 | 2-1/2 | 2.875" | 2.469" | 0.203" | 5.79 |
| 3 | 3.500" | 3.068" | 0.216" | 7.58 | 3 | 3.500" | 3.068" | 0.216" | 7.58 |
| 3-1/2 | 4.000" | 3.548" | 0.226" | 9.11 | 3-1/2 | 4.000" | 3.548" | 0.226" | 9.11 |
| 4 | 4.500" | 4.026" | 0.237" | 10.79 | 4 | 4.500" | 4.026" | 0.237" | 10.79 |
| 5 | 5.563" | 5.047" | 0.258" | 14.62 | 5 | 5.563" | 5.047" | 0.258" | 14.62 |
| 6 | 6.625" | 6.065" | 0.280" | 18.97 | 6 | 6.625" | 6.065" | 0.280" | 18.97 |
| 8 | 8.625" | 7.981" | 0.322" | 28.55 | 8 | 8.625" | 7.981" | 0.322" | 28.55 |
| 10 | 10.750" | 10.020" | 0.365" | 40.48 | 10 | 10.750" | 10.020" | 0.365" | 40.48 |
| 12 | 12.75" | 11.938" | 0.406" | 53.52 | 12 | 12.75" | 12.000" | 0.375" | 49.56 |
| 14 | 14.000" | 13.124" | 0.438" | 63.50 | 14 | 14.000" | 13.250" | 0.375" | 54.57 |
| 16 | 16.000" | 15.000" | 0.500" | 82.77 | 16 | 16.000" | 15.250" | 0.375" | 62.58 |
| 18 | 18.000" | 16.876" | 0.562" | 104.70 | 18 | 18.000" | 17.250" | 0.375" | 70.59 |
| 20 | 20.000" | 18.812" | 0.594" | 123.10 | 20 | 20.000" | 19.250" | 0.375" | 78.60 |
| 24 | 24.000" | 22.624" | 0.688" | 171.30 | 24 | 24.000" | 23.250" | 0.375" | 94.62 |
Price Terms︰ FOB Tianjin
Payment Terms︰ TT/LC/DP
Packing︰ Packed with 8 times metal belt and plastic-wrapped if need or by customers request
Lead Time︰ within 10 days
