4in c channel, 5 in c channel, 3.5 c channel
| JIS Channel steel |
| size |
h |
b |
s |
t |
weight |
size |
h |
b |
s |
t |
weight |
| mm |
mm |
mm |
mm |
mm |
(kg/m) |
mm |
mm |
mm |
mm |
mm |
(kg/m) |
| 75x40 |
75 |
40 |
3.8 |
7 |
5.3 |
125x65 |
125 |
65 |
5.3 |
6.8 |
12.17 |
| 75x40 |
75 |
40 |
4 |
7 |
5.6 |
125x65 |
125 |
65 |
5.5 |
8 |
12.91 |
| 75x40 |
75 |
40 |
4.5 |
7 |
5.85 |
125x65 |
125 |
65 |
6 |
8 |
13.4 |
| 75x40 |
75 |
40 |
5 |
7 |
6.92 |
150x75 |
150 |
75 |
5.5 |
7.3 |
14.66 |
| 100x50 |
100 |
50 |
3.8 |
6 |
7.3 |
150x75 |
150 |
75 |
5.7 |
10 |
16.71 |
| 100x50 |
100 |
50 |
4.2 |
6 |
8.03 |
150x75 |
150 |
75 |
6 |
10 |
17.9 |
| 100x50 |
100 |
50 |
4.5 |
7.5 |
8.97 |
150x75 |
150 |
75 |
6.5 |
10 |
18.6 |
| 100x50 |
100 |
50 |
5 |
7.5 |
9.36 |
150x75 |
150 |
75 |
9 |
12.5 |
24 |
| 125x65 |
125 |
65 |
5.2 |
6.8 |
11.66 |
|
|
|
|
|
|
| C Channel steel |
| size |
h |
b |
s |
t |
weight |
| mm |
mm |
mm |
mm |
mm |
(kg/m) |
| 76x38 |
76 |
38 |
5.1 |
6.8 |
6.7 |
| 102x51 |
102 |
51 |
6.1 |
7.6 |
10.4 |
| 127x64 |
127 |
64 |
6.4 |
9.2 |
14.9 |
| 152x76 |
152 |
76 |
6.4 |
9 |
17.9 |
| UPN Channel steel |
| size |
h |
b |
s |
t |
weight |
| mm |
mm |
mm |
mm |
mm |
(kg/m) |
| 50x38 |
50 |
38 |
5 |
7 |
5.59 |
| 60x30 |
60 |
30 |
6 |
6 |
5.07 |
| 65x42 |
65 |
42 |
5.5 |
7.5 |
7.09 |
| 80x45 |
80 |
45 |
6 |
8 |
8.64 |
| 100x50 |
100 |
50 |
6 |
8.5 |
10.60 |
| 120x55 |
120 |
55 |
7 |
9 |
13.40 |
| 140x60 |
140 |
60 |
7 |
10 |
16.00 |
| 160x65 |
160 |
65 |
7.5 |
10.5 |
18.80 |
| 180x70 |
180 |
70 |
8 |
11 |
22.00 |
| 200x75 |
200 |
75 |
8.5 |
11.5 |
25.30 |
